516"(8mm) Mini worm drive hose clamp can be easily installed in restricted space because it is small and light. It is also called American type hose clamp. 8mm band can generate significant sealing pressure with relatively low installation torque. Save cost and space.
.png)
516"(8mm) Mini worm drive hose clamp can be easily installed in restricted space because it is small and light. It is also called American type hose clamp. 8mm band can generate significant sealing pressure with relatively low installation torque. Save cost and space.
l Small and light, can be installed easily in some restricted applications
l Ensure tight and leak-free seal
l Band Width: 5/16"(8mm)
l Band Thickness: 0.024" (0.6mm)
l Screw: 1/4" (6mm) Hex slotted or cross screw head
l Recommended Tightening Torque: 2.1N.m
l No burrs, protect soft hose well
l Standard: SAE
l Application: Air and fuel lines, pneumatic or hydraulic systems
